Embossed Film – Flexible and Durable Technical Protection
Embossed film is a specialized technical material widely used in the production of adhesive tapes, sealing systems, and in the construction and industrial sectors. Its defining feature is a crinkled, wavy surface – known as crepe – which gives the film exceptional flexibility and high resistance to mechanical damage.
Dolpap offers both standard and silicone-coated embossed film – a type of structured film with a textured surface and a silicone coating. This silicone layer provides the anti-adhesive properties essential for demanding industrial and assembly applications.
PP
Single-sided
30 µm
35 µm
Role (szer. 30 mm - 1600 mm)
Diecuts
What Makes Embossed Film Unique?
Dolpap’s embossed film is manufactured from high-quality polypropylene (PP). It is available in 30 µm and 35 µm thicknesses, allowing you to select the most suitable option for your application. The film comes in white and black embossed film variants, and its structure ensures excellent adhesion to irregular and complex surfaces.
The silicone-coated version (silicone-coated embossed film) is produced using solventless or UV technologies, ensuring stable coating and consistent release properties throughout the product line.
Main Applications of Embossed Film
1. Industrial Tape Manufacturing
A primary use case is the production of various technical tapes, including:
- Butyl tape release film – used in roof and façade sealing
- Insulating and transfer tapes – for construction and installation applications
- Ridge tapes – for ventilation and chimney flashing
- Polyurethane and bitumen-based tapes – used in waterproofing systems
Here, the emzossed film serves as a protective film or liner, shielding adhesive layers from contamination, moisture, and premature bonding. The textured crepe surface and silicone coating allow for smooth peeling without stretching or tearing during application.
2. Construction and Roofing
Embossed film is ideal as a separating and protective layer in products such as:
- Torch-on roofing membranes
- Bitumen shingles
- Roofing and sealing tapes
- Repair components for roofs and foundations
It performs exceptionally well in challenging environments due to its resistance to tar, moisture, and weather conditions.
3. Technical and Automotive Industries
In technical and automotive fields, embossed film is used as:
- A spacer or separator during assembly or packaging
- A protective film for delicate or painted surfaces
- A carrier layer for laminates or self-adhesive components used in vehicles
Key Features and Benefits
Dolpap’s embossed film offers several important advantages:
- High flexibility – the creped surface easily conforms to curved and irregular shapes
- Mechanical durability – textured surface enhances tensile strength
- Silicone coating – enables easy release from adhesives
- Chemical resistance – effective against oils, greases, tar, and water
- Dimensional stability – remains flat and does not wrinkle during application
- Customization options – available in various widths and colors to match production needs
Standard widths range from 30 mm to 1600 mm. Delivery options include rolls and die-cut formats.
Film Type and Configuration Options
Dolpap provides full customization. In addition to choosing color (white or black embossed film) and thickness (30 or 35 µm), clients can specify:
- Silicone release strength (e.g. easy release, controlled release)
- Coating technology (solventless or UV)
- Delivery format (rolls, spools, die-cuts)
Optional technical prints (e.g. batch numbers, production codes)
Additional Services
Dolpap is not just a material producer – we offer comprehensive services such as:
- Silicone or polyethylene coating
- Precision cutting and converting
- Custom technical printing
- Laboratory testing to verify adhesion, thickness, and quality
With years of experience and modern equipment, Dolpap can deliver both standard and tailor-made orders.
Who Uses Embossed Film?
Embossed film and silicone-coated embossed film are ideal for:
- Manufacturers of industrial and construction tapes
- Roofing and insulation product suppliers
- Repair and waterproofing service providers
- Automotive and technical component producers
- Waterproofing system engineers
Suppliers of mounting and surface protection materials
Contact Us
Looking for a flexible and durable material that performs under demanding conditions? Interested in embossed film, silicone-coated embossed film, protective film, structured film, or a specialty butyl tape release film?
Get in touch with us – we’ll help you choose the perfect product for your production process.
Parameters of Embossed Film
| Product | Thickness µm |
Width mm |
Color | Release | Technologia | |||||
|---|---|---|---|---|---|---|---|---|---|---|
| transparent | white | black | red | easy | controlled | solventless | UV | |||
| PP creped | 30, 35 | 30 - 1600 | ● | ● | ● | ● | ● | |||
